Control QML Type

Abstract base type providing functionality common to all controls. More...

Properties

Detailed Description

Control is the base type of user interface controls. It receives input events from the window system, and paints a representation of itself on the screen.

Control Layout

The following diagram illustrates the layout of a typical control:

The implicitWidth and implicitHeight of a control are typically based on the implicit sizes of the background and the content item plus any padding. These properties determine how large the control will be when no explicit width or height is specified.

The background item fills the entire width and height of the control, unless an explicit size has been given for it.

The geometry of the contentItem is determined by the padding.

Event Handling

All controls, except non-interactive indicators, do not let clicks and touches through to items below them. For example, if Pane is used as the header or footer of ApplicationWindow, items underneath it will not get mouse or touch events.

See also ApplicationWindow and Container.

Property Documentation

[read-only] availableHeight : real

This property holds the height available to the contentItem after deducting vertical padding from the height of the control.

See also Control Layout, padding, topPadding, and bottomPadding.


[read-only] availableWidth : real

This property holds the width available to the contentItem after deducting horizontal padding from the width of the control.

See also Control Layout, padding, leftPadding, and rightPadding.


background : Item

This property holds the background item.

Button {
    id: control
    text: qsTr("Button")
    background: Rectangle {
        implicitWidth: 100
        implicitHeight: 40
        opacity: enabled ? 1 : 0.3
        color: control.down ? "#d0d0d0" : "#e0e0e0"
    }
}

Note: If the background item has no explicit size specified, it automatically follows the control's size. In most cases, there is no need to specify width or height for a background item.

Note: Most controls use the implicit size of the background item to calculate the implicit size of the control itself. If you replace the background item with a custom one, you should also consider providing a sensible implicit size for it (unless it is an item like Image which has its own implicit size).

See also Control Layout.


bottomPadding : real

This property holds the bottom padding.

See also Control Layout, padding, topPadding, and availableHeight.


contentItem : Item

This property holds the visual content item.

Note: The content item is automatically resized to fit within the padding of the control.

Note: Most controls use the implicit size of the content item to calculate the implicit size of the control itself. If you replace the content item with a custom one, you should also consider providing a sensible implicit size for it (unless it is an item like Text which has its own implicit size).

Button {
    id: control
    text: qsTr("Button")
    contentItem: Label {
        text: control.text
        font: control.font
        verticalAlignment: Text.AlignVCenter
    }
}

See also Control Layout and padding.


focusPolicy : enumeration

This property determines the way the control accepts focus.

ConstantDescription
Qt.TabFocusThe control accepts focus by tabbing.
Qt.ClickFocusThe control accepts focus by clicking.
Qt.StrongFocusThe control accepts focus by both tabbing and clicking.
Qt.WheelFocusThe control accepts focus by tabbing, clicking, and using the mouse wheel.
Qt.NoFocusThe control does not accept focus.

[read-only] focusReason : enumeration

This property holds the reason of the last focus change.

Note: This property does not indicate whether the control has active focus, but the reason why the control either gained or lost focus.

ConstantDescription
Qt.MouseFocusReasonA mouse action occurred.
Qt.TabFocusReasonThe Tab key was pressed.
Qt.BacktabFocusReasonA Backtab occurred. The input for this may include the Shift or Control keys; e.g. Shift+Tab.
Qt.ActiveWindowFocusReasonThe window system made this window either active or inactive.
Qt.PopupFocusReasonThe application opened/closed a pop-up that grabbed/released the keyboard focus.
Qt.ShortcutFocusReasonThe user typed a label's buddy shortcut
Qt.MenuBarFocusReasonThe menu bar took focus.
Qt.OtherFocusReasonAnother reason, usually application-specific.

See also Item::activeFocus and visualFocus.


font : font

This property holds the font currently set for the control.

This property describes the control's requested font. The font is used by the control's style when rendering standard components, and is available as a means to ensure that custom controls can maintain consistency with the native platform's native look and feel. It's common that different platforms, or different styles, define different fonts for an application.

The default font depends on the system environment. ApplicationWindow maintains a system/theme font which serves as a default for all controls. There may also be special font defaults for certain types of controls. You can also set the default font for controls by passing a custom font to QGuiApplication::setFont(), before loading the QML. Finally, the font is matched against Qt's font database to find the best match.

Control propagates explicit font properties from parent to children. If you change a specific property on a control's font, that property propagates to all of the control's children, overriding any system defaults for that property.

Page {
    font.family: "Courier"

    Column {
        Label {
            text: qsTr("This will use Courier...")
        }

        Switch {
            text: qsTr("... and so will this")
        }
    }
}

hoverEnabled : bool

This property determines whether the control accepts hover events. The default value is Qt.styleHints.useHoverEffects.

Setting this property propagates the value to all child controls that do not have hoverEnabled explicitly set.

You can also enable or disable hover effects for all Qt Quick Controls 2 applications by setting the QT_QUICK_CONTROLS_HOVER_ENABLED environment variable.

See also hovered.


[read-only] hovered : bool

This property holds whether the control is hovered.

See also hoverEnabled.


leftPadding : real

This property holds the left padding.

See also Control Layout, padding, rightPadding, and availableWidth.


locale : Locale

This property holds the locale of the control. It contains locale specific properties for formatting data and numbers. Unless a special locale has been set, this is either the parent's locale or the default locale.

Control propagates explicit locale properties from parent to children. If you change a specific property on a control's locale, that property propagates to all of the control's children, overriding any system defaults for that property.

See also mirrored and LayoutMirroring.


[read-only] mirrored : bool

This property holds whether the control is mirrored.

This property is provided for convenience. A control is considered mirrored when its visual layout direction is right-to-left; that is, when using a right-to-left locale or when LayoutMirroring.enabled is true.

See also locale, LayoutMirroring, and Right-to-left User Interfaces.


padding : real

This property holds the default padding.

Padding adds a space between each edge of the content item and the background item, effectively controlling the size of the content item. To specify a padding value for a specific edge of the control, set its relevant property:

See also Control Layout, availableWidth, availableHeight, topPadding, leftPadding, rightPadding, and bottomPadding.


rightPadding : real

This property holds the right padding.

See also Control Layout, padding, leftPadding, and availableWidth.


spacing : real

This property holds the spacing.

Spacing is useful for controls that have multiple or repetitive building blocks. For example, some styles use spacing to determine the distance between the text and indicator of CheckBox. Spacing is not enforced by Control, so each style may interpret it differently, and some may ignore it altogether.


topPadding : real

This property holds the top padding.

See also Control Layout, padding, bottomPadding, and availableHeight.


[read-only] visualFocus : bool

This property holds whether the control has visual focus. This property is true when the control has active focus and the focus reason is either Qt.TabFocusReason, Qt.BacktabFocusReason, or Qt.ShortcutFocusReason.

In general, for visualizing key focus, this property is preferred over Item::activeFocus. This ensures that key focus is only visualized when interacting with keys - not when interacting via touch or mouse.

See also focusReason and Item::activeFocus.


wheelEnabled : bool

This property determines whether the control handles wheel events. The default value is false.

Note: Care must be taken when enabling wheel events for controls within scrollable items such as Flickable, as the control will consume the events and hence interrupt scrolling of the Flickable.
