Qt Insight - Qt Quick Application

A Qt Quick application using Qt Insight Tracker.

Running the Example

To run the example from Qt Creator, open the Welcome mode and select the example from Examples. For more information, visit Building and Running an Example.

The example shows how to integrate Qt Insight Tracker to your Qt Quick application.

In the example, InsighTracker singleton is configured and then enabled.

    InsightConfiguration {
        syncInterval: 60
    }

    Component.onCompleted: InsightTracker.enabled = true;

The example is using states to control the UI layouts. Qt Insight can be then easily used to track the transitions in the UI flow either from QML:

onStateChanged: InsightTracker.transition(applicationFlow.state);

or from C++:

    tracker.transition("Home");

Button presses can also be tracked.

cappuccino.button.onClicked: {
    InsightTracker.interaction(cappuccino.coffeeText.text, cappuccino.InsightCategory.category);

    applicationFlow.cappuccino()
}

The example also sends the current color theme as additional context data in the interaction event.

function themeButton() {
    if (Colors.currentTheme == Colors.dark) {
        Colors.currentTheme = Colors.light
    } else {
        Colors.currentTheme = Colors.dark
    }

    InsightTracker.interaction("theme", "dark theme", Colors.currentTheme == Colors.dark);
}

The example sends custom dimension CoffeeType that can be used in the Insight Console to filter sessions that selected specific coffee variety.

function onFinished() {
    InsightTracker.dimensionData("CoffeeType", coffeeText.text);

    stack.push(ready)
    applicationFlow.state = "Ready"
}

An attached property InsightCategory can be used in the QML components. It can be used to filter the tracked events.

CoffeeCard {
    id: cappuccino
    coffeeName: "Cappuccino"
    ingredients: "Milk, Espresso, Foam"
    time: 2
    cupsLeft: applicationFlow.cappuccinos

    InsightCategory.category: "coffee"
}

Tracked events are always associated with a session, which is always new for each application launch. A new session can also be created if needed. In the example, this is done when the UI is reset back to the initial state.

function onReturnToStart() {
    stack.pop(stack.get(0))
    applicationFlow.state = "Home"
    applicationFlow.progressBarValue = 0
    applicationFlow.progressCupState = "0"

    InsightTracker.startNewSession();
}

Example project @ code.qt.io
