PieSlice QML Type
代表饼系列中的一个切片。更多
Import Statement: | import QtGraphs |
In C++: | QPieSlice |
- 所有成员的列表,包括继承成员
- PieSlice 是Qt Graphs QML Types for 2D 的一部分。
属性
- angleSpan : real
- borderColor : color
- borderWidth : real
- color : color
- explodeDistanceFactor : real
- exploded : bool
- label : string
- labelArmLengthFactor : real
- labelColor : color
- labelFont : font
- labelPosition : enumeration
- labelVisible : bool
- percentage : real
- startAngle : real
- value : real
信号
- angleSpanChanged()
- borderColorChanged()
- borderWidthChanged()
- colorChanged()
- explodeDistanceFactorChanged()
- explodedChanged()
- labelArmLengthFactorChanged()
- labelChanged()
- labelColorChanged()
- labelFontChanged()
- labelFontChanged()
- labelPositionChanged()
- labelVisibleChanged()
- percentageChanged()
- startAngleChanged()
- valueChanged()
详细说明
饼片有一个值和一个标签。当切片被添加到饼系列中时,PieSeries 类型会计算切片与系列中所有切片总和的百分比,以确定图形中切片的实际大小。
默认情况下,标签是隐藏的。如果标签可见,它可以位于切片外侧并用一条臂与切片相连,也可以位于切片内侧的中心位置,可以水平放置,也可以与切片圆弧的切线或法线平行放置。
默认情况下,切片的视觉外观由主题设置,但可以通过指定切片属性来覆盖主题。不过,如果在自定义切片后更改主题,所有自定义功能都将丢失。
PieSlice 类型应作为PieSeries 类型的子类型使用。例如
PieSeries { PieSlice { label: "example" value: 1 } }
另外,也可以使用PieSeries.append() 方法将切片添加到饼系列中。
在这种情况下,可以使用PieSeries.at() 或PieSeries.find() 访问单个 PieSlice 实例的属性。
另请参阅 PieSeries 。
属性文档
angleSpan : real |
切片的跨度,单位为度。一个完整的派是 360 度,其中 0 度为 12 点钟方向。切片添加到系列后自动更新。
borderColor : color |
用于绘制切片边框的颜色。
另请参阅 borderWidth 。
borderWidth : real |
切片边框的宽度。这是一个方便修改切片边框宽度的属性。
另请参阅 borderColor 。
color : color |
切片的填充颜色。
exploded : bool |
切片是否与饼分离。
另请参阅 explodeDistanceFactor 。
label : string |
切片的标签。
注: 字符串可以是 HTML 格式。
labelArmLengthFactor : real |
labelColor : color |
用于绘制切片标签的颜色。
labelFont : font |
labelPosition : enumeration |
描述切片标签的位置。
常数 | 描述 |
---|---|
PieSlice.LabelPosition.Outside | 标签位于用臂连接的切片外部。这是默认值。 |
PieSlice.LabelPosition.InsideHorizontal | 标签位于切片中心,水平放置。 |
PieSlice.LabelPosition.InsideTangential | 标签在切片内居中,旋转后与切片圆弧的切线平行。 |
PieSlice.LabelPosition.InsideNormal | 标签在切片内居中,旋转后与切片圆弧的法线平行。 |
另请参阅 labelVisible 。
labelVisible : bool |
切片标签的可见性。默认情况下,标签不可见。
percentage : real |
切片占系列中所有切片总和的百分比。实际值从 0.0 到 1.0 不等。切片添加到系列后自动更新。
startAngle : real |
该切片在所属系列中的起始角度。一个完整的饼是 360 度,其中 0 度为 12 点钟方向。切片添加到系列后自动更新。
value : real |
切片的值。
注意: 负值会转换为正值。
信号文档
angleSpanChanged() |
borderColorChanged() |
borderWidthChanged() |
colorChanged() |
当切片颜色发生变化时,将发出此信号。
注: 相应的处理程序是onColorChanged
。
explodeDistanceFactorChanged() |
explodedChanged() |
labelArmLengthFactorChanged() |
labelChanged() |
labelColorChanged() |
labelFontChanged() |
labelFontChanged() |
labelPositionChanged() |
labelVisibleChanged() |
percentageChanged() |
startAngleChanged() |
valueChanged() |
