Qt Quick 3D Xr

简介

扩展现实(XR)是一个术语,包括虚拟现实(VR)、增强现实(AR)和混合现实(MR)。这些技术可创造身临其境的体验,改变用户对周围世界的感知。Qt Quick 3D Xr 模块提供了用于开发 XR 应用程序的 API,Qt Quick 3D ,适用于各种设备和平台。

Qt Quick 3DQt Quick 3D Xr 应用程序之间的区别

入口点

从开发人员的角度来看,Qt Quick 3DQt Quick 3D Xr 应用程序的主要区别在于场景的切入点,了解现实世界中的单位和跟踪数据至关重要。

Qt Quick 3D 中,一个最小的应用程序由摄像头、灯光和 3D 模型组成。这些元素的定位和大小是在场景坐标系中定义的,而坐标系是任意的,可以由开发者根据应用的需要来定义。

View3D {
    width: 1280
    height: 720

    PerspectiveCamera {
        position: Qt.vector3d(0, 200, 300)
    }

    DirectionalLight {
    }

    Node {
        id: sceneRoot
        Model {
            id: model
            position: Qt.vector3d(0, -200, 0)
            source: "#Cylinder"
            materials: [ PrincipledMaterial {
                    baseColor: "red"
            }]
        }
    }
}

在 XR 应用程序中,定义场景时要考虑现实世界的单位和跟踪数据。摄像头的位置和方向由设备定义,如果是头戴式显示器(HMD),则由用户的头部位置和方向定义。场景的单位应与真实世界的单位相匹配。例如,您希望真实世界中的门或桌子与虚拟世界中的大小相同。

注: Qt Quick 3D Xr 应用程序的入口点不是View3D ,而是XrView 。此外,XrOrigin 定义了场景的原点,即跟踪项相对于原点的位置。

XrView {
    DirectionalLight {
    }

    xrOrigin: XrOrigin {
        XrController {
            id: rightController
            controller: XrController.ControllerRight
        }
        XrController {
            id: leftController
            controller: XrController.ControllerLeft
        }
    }

    Node {
        id: sceneRoot
        Model {
            id: floor
            source: ":meshes/floor.mesh"
            materials: [ PrincipledMaterial {
                    baseColor: "green"
                }]
        }

        Model {
            id: table
            property real height: 0.7
            position: Qt.vector3d(0, height - 2.5, 0)
            source: ":meshes/table.mesh"
            materials: PrincipledMaterial {
                baseColor: "white"
            }
        }

        Model {
            id: monitor
            source: ":meshes/monitor.mesh"
            y: table.height
            XrItem {
                id: theScreen
                y: monitor.yOffset + height
                x: -width / 2
                width: monitor.width
                height: monitor.height
                contentItem: ScreenContent {}
            }
        }
    }
}

其他 CMake 函数

从所有Qt Quick 3D Xr 示例CmakeLists.txt 文件中可以看出,您需要在项目的顶层 CMakeLists 文件中添加一些函数。

在项目的 CMakeLists 文件中添加此行,即可指定自定义AndroidManifest.xml 并确保其被使用:

if(ANDROID)
    set_property(TARGET xr_simple APPEND PROPERTY QT_ANDROID_PACKAGE_SOURCE_DIR ${CMAKE_CURRENT_SOURCE_DIR}/android)
endif()

有关设置AndroidManifest.xml 的更多详情,请参阅Meta Quest 3 入门页面的相关部分。

CMakeLists.txt 的更改同样适用于 visionOS,我们在其中包含了MacOSXBundleInfo.plist.in 文件:

if (APPLE AND CMAKE_SYSTEM_NAME STREQUAL "visionOS")
    set_target_properties(xr_simple PROPERTIES
        MACOSX_BUNDLE_GUI_IDENTIFIER io.qt.xr_simple
        MACOSX_BUNDLE_INFO_PLIST ${CMAKE_CURRENT_SOURCE_DIR}/visionos/MacOSXBundleInfo.plist.in
    )
endif()

何去何从?

请参阅Meta Quest 3 入门Apple Vision Pro 入门,了解有关如何开始使用特定设备的更多信息。有关支持的平台和设备的更多信息,请参阅 "支持的平台 "页面。

如果您正在查找特定的Qt Quick 3D Xr API,请查看API Reference ,或试用Qt Quick 3D Xr 示例,其中演示了如何使用Qt Quick 3D Xr API。
